Chipset: Intel H610 Chipset
Rozmerový formát: mATX ( 23.4 cm x 20.3 cm )
Podpora pre procesory: 14 Gen Intel® Core™ & 13 Gen Intel® Core™ & 12 Gen Intel® Core™, Pentium Gold and Celeron Processors
Pätica procesora: LGA1700
Pozícia na pamäti: 2 x DIMM, Dual Channel Memory Architecture
Podpora pre pamäte: DDR4 3200/3000/2933/2800/2666/2400/2133 MHz
Max.veľkosť operačnej pamäte: 64 GB
Podpora pre pamäte typu: XMP
Grafické výstupy: (na základe procesora)
1 x D-Sub port
1 x HDMI port
Zvuková karta: Realtek 7.1 Surround Sound High Definition Audio CODEC
Sieťová karta: 1 x Realtek 1Gb Ethernet
Rozširujúce sloty:
1 x PCIe 4.0 x16 slot
1 x PCIe 3.0 x1 slot
SATA: 4 x SATA 6Gb/s ports
M.2: 1 x M.2 slot
USB:
Interné:
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
Externý:
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Interné porty:
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
1 x M.2 slot (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
Miscellaneous
1 x RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel header
Externé porty:
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
1 x D-Sub port
1 x HDMI port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port
BIOS: UEFI AMI BIOS, 128 Mb Flash ROM
